Panasonic CF-H-C-MD-122 Havis 11 Slide Out Locking Swing Arm with Motion Adapter
SKU
CF-H-C-MD-122
Model No
CF-H-C-MD-122
$426.32
Product Highlights
- Ruggedized design adds protection for improved safety of occupants and equipment
- 360 degrees of smooth rotation for ideal computing device viewing angles from both the driver and front passenger seats
- Swing arm has 24 locking points, or every 15 degrees of rotation to maximize placement options
- Rotation tension is adjustable with hand tools, no disassembly required
- Material: rugged heavy gauge black powder coated steel and machined 6061 aircraft aluminum for strength, durability, and rust prevention
Speak to an expert
The Panasonic CF-H-C-MD-122 Havis 11 Slide Out Locking Swing Arm with Motion Adapter is designed to enhance the functionality and ergonomics of mobile workstations. With its innovative features, this swing arm provides maximum comfort and versatility, allowing users to easily adjust their equipment while ensuring safety and stability on the road.
Panasonic CF-H-C-MD-122 Havis 11 Swing Arm Features
- Easy Slide Travel: The arm allows for 6" of smooth gliding action, providing effortless movement and adjustment.
- Comfort Grip Locking Knob: The front-facing knob enables locking in any position and adjusts the effort needed to move the slide, enhancing user control.
- Space-Saving Design: Safely stow equipment close to the dash when not in use, effectively freeing up valuable cabin space.
- Ergonomic Front Access Control: Easily operate the arm's rotation with a user-friendly control lever that promotes comfort and ease of use.
- Flexible Positioning: Offers maximum comfort and better ergonomics for users, adjusting to various seating positions.
- C-MD-204 Motion Adapter: Includes an adapter that provides up to 180 degrees of rotation and 45 degrees of tilt for versatile equipment positioning.
- Rugged Protection: The durable design enhances safety for both occupants and equipment, ensuring longevity and reliability.
- 360-Degree Rotation: Enables ideal viewing angles for computing devices from both the driver and passenger seats.
- Multiple Locking Points: The arm features 24 locking points, allowing adjustments every 15 degrees for optimal placement.
- Adjustable Tension: The rotation tension can be adjusted with hand tools without requiring disassembly, facilitating user-friendly customization.
- Durable Materials: Constructed from heavy gauge black powder-coated steel and machined 6061 aircraft aluminum, ensuring strength, durability, and rust prevention.
- Mounting Compatibility: Features a 4-hole mounting pattern at 2.125" square, with 1/4" mounting hardware included for easy installation.
Panasonic CF-H-C-MD-122 Detailed Specifications
| Feature | Details |
| Model | CF-H-C-MD-122 |
| Slide Travel | 6 inches |
| Material | Black powder-coated steel, machined 6061 aircraft aluminum |
| Rotation | 360 degrees |
| Locking Points | 24 (every 15 degrees) |
| Adapter | C-MD-204 (180 degrees rotation, 45 degrees tilt) |
| Mounting Pattern | 4 hole @ 2.125" square |
| Weight Capacity | Up to standard mobile workstation equipment |
SKU  | CF-H-C-MD-122 |
|---|---|
| Manufacturer | Panasonic |
