Panasonic 7170-0219 Gamber-Johnson Tablet Display Mount Kit with Ts5 Motion Attachment

Panasonic 7170-0219 Gamber-Johnson Tablet Display Mount Kit with Ts5 Motion Attachment

Vehicle Base attaches to the passenger side seat studs. Designed using heavy gauge steel for long-term durability. The Lower Tube provides vertical clearance over the center console or the seat. Center Upper Pole allows for closer mounting to the dash and less stress on the vehicle mounting equipment as weight is centered on the pole. Wrench is needed for loosening, tightening or height adjustment. Locking Slide Arm can rotate around 360° with locking points every 15°. Slide Arm can extend out from 9" to 13" from center pole and locks automatically in the retracted 9" position. Motion Attachment has tilt capabilities up to 90° forward/26° backward and can be swiveled up to 360°. Motion Attachment works with VESA 75mm, Gamber-Johnson 2x4, NEC or AMPS hole patterns. Support Brace provides additional mount system support in rugged driving conditions and increases mounting system rigidity.

Key Features of Panasonic 7170-0219

• Heavy Gauge Steel Construction: Ensures long-term durability, making it suitable for rugged environments and demanding use.
• Lower Tube Clearance: Offers vertical space over the center console, enhancing accessibility and comfort during operation.
• Center Upper Pole Design: Positions the mount closer to the dash for improved stability and reduced stress on vehicle equipment.
• Versatile Locking Slide Arm: Rotates 360° with 15° locking points, accommodating varied angles for user preference.
• Adjustable Slide Arm Length: Extends from 9" to 13", allowing flexibility in positioning the device for optimal viewing and operation.
• Advanced Motion Attachment: Tilt capabilities of 90° forward and 26° backward with 360° swivel enable easy adjustments based on user needs.
• Compatible VESA Patterns: Works with VESA 75mm, Gamber-Johnson 2x4, NEC, or AMPS patterns, providing broader device compatibility.
• Support Brace Stability: Additional support for rugged conditions, enhancing system rigidity and securing the mounting position.

Panasonic 7170-0219 Detailed Specifications
