Platinum Tools 106280 Cat8 Shielded Toolless RJ45 Connector

The Platinum Tools Cat8 connector offers an innovative and efficient solution for terminating oversized cables. With its toolless design, users can easily strip, align, and terminate their cables without the need for specialized tools, making installation faster and hassle-free.

Key Features of Platinum Tools Cat8 Connector

• Toolless Design: Snap closed to terminate, simplifying the installation process.
• No Crimp Tool Required: Eliminate the need for expensive and complicated crimping tools.
• Compatibility: Works seamlessly on all standard cables including Cat8, Cat7, Cat6A, Cat6, and Cat5e.
• Compliance: Plenum rated and complies with UL and RoHS standards for safety and environmental considerations.
• Gold Plated Contacts: 50 micron gold plating ensures a reliable connection and enhances performance.
• Cable Suitability: Compatible with solid or stranded cables ranging from 26 to 23 AWG.
• Country of Origin: Manufactured in Taiwan ensuring high quality.
• Insulation Diameter: Accommodates sizes from 0.032” to 0.057” (0.8mm - 1.47mm) for a better fit.
• Cable Outer Diameter: Designed to work with cables having an outer diameter of 0.197” to 0.390” (5.0mm - 9.9mm).

Platinum Tools Cat8 Connector Specifications
