Platinum Tools 106197C RJ45 Cat6A 10 Gig Shielded with Liner, Stranded, 50/Clamshell

Streaming media whether data, audio or video, is on a sharp rise and users are demanding more bandwidth. That means bigger cable, commonly referred to as CAT6e, CAT6A and CAT7, and usually shielded. For maximum performance, connector and crimp tool choice is critical. Our CAT6A/10Gig termination system not only meets, but exceeds these requirements.

Features

• Max cable OD: 8.5mm/0.335" - Ensures compatibility with various jacks and enclosures for flexible installation options.
• Max conductor OD: 1.35mm/0.053" - Optimized for peak performance and reduced signal loss.
• Individual conductor OD range: 0.042” - 0.053” (1.07mm-1.35mm) - Accommodates a broad range of wiring applications.
• Wire gauge range (AWG): 24—22 - Versatile enough for different installations while maintaining robustness.
• Designed for both shielded and unshielded cabling: Provides flexibility based on installation environment and requirements.
• 50µ Gold Contacts: Enhances conductivity and reduces tarnishing for long-lasting reliability.
• UL and RoHS compliant: Ensures that the product meets safety and environmental standards, giving peace of mind to users.

Platinum Tools 106197C RJ45 Cat6A 10 Gig Shielded with Liner Features

Detailed Specifications for Platinum Tools 106197C
