GE Security Interlogix VT1500-R3 Video Transmitter / Data Receiver, MM, 2 Fibers

SKU
VT1500-R3
Model No
VT1500-R3
$770.00
Qty:
Product Highlights
    • AM Video Transmission
    • NTSC, PAL, SECAM Compatible
    • Full Color Compatibility
    • Supports RS-232 or RS-422 Data Interfaces
    • Transparent to Data Encoding/Compatible with Major CCTV Camera Manufacturers

The VT1500-R3 from Interlogix is a series video and data transceiver supports the simultaneous transmission of video and one-way return data over one or two multimode optical fibers. The module is universally compatible with major CCTV camera manufactures and supports RS-232 and RS-422 data interfaces and all major data protocols. Plug-and-play design ensures ease of installation requiring no electrical or optical adjustments. The modules incorporate power, video presence, optional contact closure, data out, and AGC status indicating LED’s to monitor proper system operation. The VR1500WDM-CC features an optional contact closure input that allows an additional device such as a dome tamper switch or alarm input to be added and its signal transmitted back to the monitoring location. This feature eliminates the need for installing additional wiring to support the alarm contact closure. The modules are available in either stand-alone or rack mount.

Features

  • AM Video Transmission
  • NTSC, PAL, SECAM Compatible
  • Full Color Compatibility
  • Supports RS-232 or RS-422 Data Interfaces
  • Transparent to Data Encoding/Compatible with Major CCTV Camera Manufacturers
  • Full Range Automatic Gain Control (AGC)
  • No In-field Electrical or Optical Adjustments Required
  • Power, Video Presence, Data Out, and AGC Status Indicating LED’s to Monitor System Performance
  • Integrated WDM for Greater Product Reliability
  • Distances up to 2.5 miles (4 km) without Repeaters
  • Hot-Swappable Rack Modules
  • Automatic Resettable Fuses on all Power Lines
SKU  VT1500-R3
Manufacturer  Interlogix
Fiber Optic Transmission use  Serial Data, Video
Channels  1 Channel
Connection Type  ST
Format  Multi-Mode
Mounting Options  Rack Mount
