The VR7430-2DRDT-R3 from Interlogix is a 4 Channel Digital Video Receiver / 2 Channel Data Transceiver, SM Laser, 1 Fiber, Rack Mount. The video transmitter/data transceiver and video receiver/data transceiver series utilize state-of-the-art 8-bit digital encoding and decoding for high-quality video transmission that exceeds the requirements of EIA RS-250C for Medium-Haul Video Transmission. These environmentally hardened units provide transmission of four independent video channels and two bi-directional data channel over one optical fiber and are ideal for use in unconditioned roadside or out-of-plant installations. Completely transparent to and universally compatible with any NTSC, PAL, or SECAM CCTV camera system, data channels can be set independently for RS-232, RS-422 and 2 or 4-wire RS-485 with tri-state support. Plug-and-play design ensures ease of installation and no electrical or optical adjustments are ever required. LED indicators are provided for rapidly ascertaining equipment operating status, and these units are available in either stand-alone or rack mount configurations.
Interlogix VR7430-2DRDT-R3 Key Features
8-Bit Digitally Encoded Video Transmission Transmits 4 Real-Time Color Video Signals and 2 Bi-Directional Data Signal on One Single-mode Optical Fiber: Ensures high-quality video and data transmission over a single fiber, reducing installation complexity and costs.
Supports RS-232, RS-422, and 2 or 4-wire RS-485 with Tri-State Data Interfaces: Provides flexible connectivity options for various data communication needs.
LED Status Indicators Provide Rapid Indication of Critical Operating Parameters: Facilitates quick troubleshooting and monitoring of system performance.
Exceeds All Requirements for RS-250C Medium-Haul Transmission: Guarantees exceptional video performance suitable for professional surveillance applications.
Exceptionally Low Video Distortion with Zero Performance Variation vs. Optical Path Loss: Maintains video quality over longer distances without degradation.
Ideally Suited to Networks Requiring Multiple Physical Layers Where Video Degradation May be a Problem: Perfect for complex surveillance setups needing reliable video transmission.
Directly Compatible with All NTSC, PAL, or SECAM CCTV Camera Systems: Offers versatility and easy integration into existing security systems.
NTCIP Compatible: Ensures compliance with industry standards for traffic management systems.
Tested and Certified by an Independent Testing Laboratory for Full Compliance with the Environmental Requirements: Assures robustness and reliability in challenging environments.
Robust Design Ensures Extremely High Reliability In Unconditioned Out-of-Plant Environments: Ideal for outdoor installations that require durability against the elements.
Solid-State Current Limiters on All Power Lines Provide Unconditional Equipment Protection: Enhances safety and reliability by safeguarding against power surges.
VR7430-2DRDT-R3-Specsheet
