Comnet FVR10D1A2C1M1 Video Receiver/Data Transceiver, Audio Receiver

The ComNet™ FVR10D1A2C1M1 Video Receiver/Data Transceiver is engineered for high-quality video and audio transmission, utilizing advanced 10-bit digital encoding for superior performance. With the ability to transmit one independent video channel, bi-directional data, and audio signals over a single optical fiber, this device excels in environments where reliability and performance are critical. It's perfect for unconditioned roadside and out-of-plant installations, offering robust design and ease of installation with a plug-and-play feature.

ComNet FVR10D1A2C1M1 Video & Audio Features

• 10-bit digital video transmission: transmits one real-time color video signal and one bi-directional data signal on one optical fiber for high-quality video performance.
• Supports multiple data formats: compatible with RS232, RS422, and 2 or 4-wire RS485, enhancing versatility in communication.
• Two bi-directional Audio Channels: facilitates clear audio transmission, enhancing the overall communication experience.
• One bi-directional Contact Closure: allows for effective alarm signaling and system monitoring.
• 24-Bit 96kHz Digitally Encoded Transmission: ensures high-fidelity audio quality for professional applications.
• 20Hz – 18 kHz Audio Bandwidth: accommodates a wide range of audio frequencies for optimal sound reproduction.
• 600 Ohms Audio Input Impedance: optimized for compatibility with standard audio equipment.
• Transmits Balanced Line-Level Audio up to +6dBm: provides high-quality sound transmission without interference.
• Exceeds EIA RS-250C requirements: offers extremely high video performance for reliable short-haul video transmission.
• Low video distortion: ensures zero performance variation vs. optical path loss for steady signal quality.
• Multiple physical layer compatibility: ideal for networks where video degradation is a concern; supports video systems without compromising quality.
• Universal compatibility: works seamlessly with all NTSC, PAL, or SECAM CCTV camera systems.
• Full environmental compliance: meets NEMA TS-1/TS-2 and Caltrans specifications for rigorous conditions, ensuring durability.
• Voltage transient protection: safeguards against power surges and other voltage transient events, enhancing longevity.
• Robust design: assures high reliability in unconditioned out-of-plant environments, suitable for demanding applications.
• Bi-color LED status indicators: provides quick insight into critical operating parameters, aiding maintenance.
• Hot-swappable rack modules: allows for easy upgrades and replacements without disrupting service.
• Interchangeable design: supports both stand-alone and rack mount usage with ComFit, offering flexibility in installation.

ComNet FVR10D1A2C1M1 Detailed Specifications
