Pelco FTV80S1FC 8 Channel Single Mode Fiber Transmitter, FC FTV80S1FC by Pelco

Pelco FTV80S1FC 8 Channel Single Mode Fiber Transmitter, FC

Pelco FTV80S1FC 8 Channel Single Mode Fiber Transmitter, FC

by Pelco
  • Pelco FTV80S1FC 8 Channel Single Mode Fiber Transmitter, FC Pelco FTV80S1FC 8 Channel Single Mode Fiber Transmitter, FC

SKU: FTV80S1FC

Model #: FTV80S1FC

Availability: Usually ships the next business day

$2,395.43

Low Price Guarantee

Quick Overview



    • Multimode Fiber Support for Distances up to 3 km (1.9 mi)

    • Single-Mode Fiber Support for Distances up to 48 km (29.8 mi)

    • Compatible with NTSC, PAL, or SECAM Video Standards

    • Laser Diode for Transmission of Optical Signals

    • Voltage Transient Protection on All Power and Signal Input/Output Lines


UPC: 700880297667

  • Express Checkout:
  • Checkout with PayPal

See any errors on this page? Let us know.

Product Details

The FTV80 fiber transmitter and receiver transmit eight channels of video over one optical fiber in a two-slot wide design. The FTV80 transmitter are available in multimode and single-mode versions. The FTV80 plug-and-play design ensures ease of installation by requiring no electrical or optical adjustments. Modular in design, FTV80 units can be rack-mounted using the EURACK/USRACK chassis, or stand-alone modules can be placed on a desktop or mounted to a wall (wall mount kit not required). For stand-alone and wall mount installations, external power is required for the FTV80 units. The units can be powered with the recommended FEXTPS fiber external power supply.

Features

  • 10-Bit Digitally Encoded Video for High-Quality Multichannel Video Transmission over a Single Fiber
  • Multimode Fiber Support for Distances up to 3 km (1.9 mi)
  • Single-Mode Fiber Support for Distances up to 48 km (29.8 mi)
  • Exceeds All Requirements for EIA RS-250C Short-Haul Transmission Specifications
  • Compatible with NTSC, PAL, or SECAM Video Standards
  • Designed to Meet NEMA TS 1/TS 2 and Caltrans Traffic Signal Control Equipment Environmental Standards
  • Laser Diode for Transmission of Optical Signals
  • Voltage Transient Protection on All Power and Signal Input/Output Lines
  • LED Status Indicators for Monitoring All Critical Operating Parameters
  • Stand-Alone or Rack-Mountable Modular Design

Downloads

  FTV80S1FC-Specsheet

Product Specifications

SKU  FTV80S1FC
Manufacturer  Pelco
Capacity Inputs 8
