Comnet CLLFE4POEC Local 4 Channel Ethernet-over-COAX Extender With 30W PSE PoE+
SKU
CLLFE4POEC
Model No
CLLFE4POEC
was $2,165.00 Special Price $2,099.00
Product Highlights
- Transmits individual Ethernet data channels with PoE+ Power Injection or Pass-through PoE+ over Coaxial cable
- Extends Ethernet up to 5,000 feet (1,524 m) at 10 Mbps or 2,000 feet (610 m) at 100 Mbps over Coaxial cable
- Extended temperature operation from -40°C to +75°C
- Extended Pass-through PoE meets the IEEE 802.3at standard for Power over Ethernet
- Full 10/100 Mbps Bandwidth
Speak to an expert
The ComNet™ CopperLine® CLLFE4POEC is an advanced Local 4 Channel Ethernet-over-COAX Extender that seamlessly supports high-speed Ethernet transmission while delivering Power over Ethernet (PoE+) capabilities. Designed for long-distance connectivity, this reliable equipment extends Ethernet and power over coaxial cable, meeting various networking needs with utmost flexibility and efficiency.
ComNet CLLFE4POEC - Key Features
- Power over Ethernet Integration: Transmits individual Ethernet data channels with PoE+ Power Injection or Pass-through PoE+ over Coaxial cable, allowing for powered device connectivity without separate power lines.
- Long-Distance Extensions: Extends Ethernet up to 5,000 feet (1,524 m) at 10 Mbps or 2,000 feet (610 m) at 100 Mbps, perfect for expansive installations.
- Robust Operating Temperature: Extended temperature operation from -40°C to +75°C ensures functionality in extreme environments.
- IEEE 802.3at Compliance: Extended Pass-through PoE meets the standard for reliable power delivery to IP cameras and other PDs.
- High Bandwidth Support: Full 10/100 Mbps bandwidth capabilities support diverse networking requirements, suitable for various applications.
- Data Transmission Versatility: Supports Multicast, Unicast, and Jumbo Frame for a flexible networking experience.
- Symmetric Bandwidth: Provides consistent upload and download speeds with virtually zero packet loss over usable distances.
- RFC-2544 Compliance: Type tested to meet TCP/IP network bandwidth packet transmission standards for assured performance.
- User-Selectable Data Rate: Adjust data rate settings for maximum bandwidth or extended distance utilization based on needs.
- Comprehensive Protocol Support: Complies with major IEEE standards and RFC network protocols for seamless integration.
- Independent Laboratory Certification: Tested for compliance with environmental requirements of NEMA TS-1/TS-2 and CALTRANS Traffic Signal Control Equipment Specifications.
- LED Status Indicators: Confirm operating status with visual alerts for quicker troubleshooting.
- Interchangeable Design: Available in ComFit interchangeable standalone formats, promoting versatility in deployment.
- Made in the USA: Designed and manufactured in the USA, ensuring high-quality standards and performance.
ComNet CLLFE4POEC - Detailed Specifications
| Model | ComNet CLLFE4POEC |
| Channel Type | 4 Channel Ethernet-over-COAX |
| Ethernet Speed | 10/100 Mbps |
| Maximum Distance | 5,000 ft (1,524 m) at 10 Mbps; 2,000 ft (610 m) at 100 Mbps |
| Power Input Range | 48 to 56 VDC |
| Operating Temperature | -40°C to +75°C |
| Standards Compliance | IEEE 802.3at, NEMA TS-1/TS-2 |
| Testing Certification | Independent lab-certified for environmental compliance |
| Dimensions | Model-specific, available in small package sizes |
| Manufacturing Location | USA |
SKU  | CLLFE4POEC |
|---|---|
| Manufacturer | Comnet |
There are no related videos.
Write Your Own Review
Manuals & Specifications
CLLFE4POEC-Specsheet CLLFE4POEC-Manual
