Axis 0584-021 Q7436 6-Channel Video Encoder Blades (10 PK)

SKU
0584-021
Axis 0584-021 Q7436 6-Channel Video Encoder Blades (10 PK) 0584-021 by Axis
Axis 0584-021 Q7436 6-Channel Video Encoder Blades (10 PK) 0584-021 by Axis
Model No
Q7436 VIDEO ENCODER BLADE BULK 10 PCS
$13,612.69
Qty:

Product Highlights
    • Outstanding video processing performance
    • 60/50 fps support
    • Coax PTZ control
    • Intelligent video capabilities
    • H.264 and Motion JPEG

The pack of 10 Q7436 6-Channel Video Encoder Blades from Axis Communications is a high performance solution for video encoder racks that enables a large number of analog cameras to be integrated into an IP-based, high-density video surveillance system suitable for demanding locations such as airports, railway stations, and city surveillance. The Q7436 blades fit perfectly into the AXIS Q7920 Video Encoder Chassis, which is a rack mount encoder chassis with support for up to 84 analog cameras. Each video encoder blade enables 6 analog video channels to be converted into high-quality H.264 and Motion JPEG streams. The blades can deliver multiple, individually configurable video streams from each channel at full frame rate in all resolutions.

With support for up to 60/50 frames per second, the encoder blades provide smooth video in high motion streams. They also offer image features such as reduced noise, enhanced sharpness, and optimized contrast, allowing for even better image quality output. The encoder blades provide remarkable performance and intelligent video capabilities, such as tampering alarm and motion detection, in addition to AXIS Camera Application Platform applications. Each video encoder blade offers significant installation savings by allowing PTZ control over coaxial cable (Coaxitron compatible) in addition to the standard support for PTZ cameras using the serial ports.

Features

  • Outstanding video processing performance
  • 60/50 fps support
  • Coax PTZ control
  • Intelligent video capabilities
  • H.264 and Motion JPEG
SKU  0584-021
Manufacturer  Axis
No Of Channels  6 Channel
Resolution   720 X 576
Compression Method   H.264, MJPEG
Protocols  ARP, Bonjour, CIFS/SMB, DHCP, DNS, DynDNS, FTP, HTTP, HTTPS, ICMP, IGMP, Ipv4/v6, NTP, QoS layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, SNMPv1/v2c/v3(MIB-II), SOCKS, TCP, UDP, UPnP
Features  Aspect Ratio Correction, De-Interlace, Privacy Masking, PTZ Support, Video Termination
connector 6x analog composite video BNC inputs
Frame rate  H.264: Up to 60/50 fps (NTSC/PAL) fps in all resolutions, Motion JPEG: Up to 60/50 fps (NTSC/PAL) fps in all resolutions
Event Trigger Intelligent video, Video loss, External inputs
PTZ Support   Yes
De-Interlace Yes
Video Termination Yes
Privacy Masking Yes
Aspect Ratio Correction Yes
There are no related videos.
SKU
0584-021
Availability: In stock
