Seco-Larm SA-026Q Miniature Programmable Timer

The ENFORCER® SA-026Q Miniature Programmable Timer is an essential component for extending the activation time of momentary contact switches, designed to operate seamlessly with 12 to 24 volts AC or DC. This timer offers a customizable delay range from 1 to 180 seconds, making it ideal for various applications including electrical locks without built-in time delays. Its compact design allows for easy installation in tight spaces, providing both convenience and reliability.

Seco-Larm SA-026Q Timer Key Features

• Adjustable Timer: Customize the delay from 1 to 180 seconds using an onboard potentiometer to fit different application needs.
• NO/NC Switch Trigger: Provides flexibility in installation by accommodating Normally Open or Normally Closed configurations.
• Compact Design: Measuring only 13/16”x29/32”x5/8” (30x58x16 mm), this timer fits conveniently in a single-gang box or door frame cavity.
• Wide Voltage Operation: Operates on 12-24 VAC or VDC, ensuring compatibility with a variety of systems.
• Low Current Consumption: Efficient operation with only 2mA in standby and 75mA when active, reducing overall energy costs.
• Relay Output: Form C (SPDT) relay output through terminal blocks allows for easier wiring and connection customization.
• Rated Contacts: Supports up to 2A@24VDC, delivering adequate power for various devices.
• Built-in Buzzer Output: 100mA@24VDC buzzer output alerts users upon activation, enhancing usability.
• Installation Accessories: Comes with double-sided foam tape for quick and easy mounting.

Seco-Larm SA-026Q Detailed Timer Specifications
