Altronix AL400ULACM Access Power Controller w/ Power Supply/Charger, 8 Fused Relay Outputs, 12/24VDC @ 4A, FAI, 115VAC, BC400 Enclosure

SKU
AL400ULACM
Model No
AL400ULACM
$279.90
Volume Discounts Volume
Discounts
Free System Design Free System
Design
Lifetime Tech Support Lifetime
Tech Support
Free Shipping Over $450* Free Shipping
Over $450*
Product Highlights
  • Filtered and electronically regulated outputs
  • Short circuit and thermal overload protection
  • Built-in charger for sealed lead acid or gel type battery backup
  • AC input and DC output LED indicators
  • Low battery and battery presence supervision

The AL400ULACM from Altronix is a Power Supply/Charger with multi-Output Access Power Controller that converts a 115VAC 60Hz input into eight (8) independently controlled power limited fuse protected Fail-Safe and/or Fail-Secure outputs with a total of 12VDC @ 4 amp or 24VDC @ 3 amp of continuous supply current. The fire alarm disconnect feature enables emergency egress in the event when the fire alarm system is activated. It is individually selectable for any or all of the eight (8) outputs.

The AL400ULACM features Short circuit and thermal overload protection, filtered and electronically regulated outputs, an AC power LED indicator and zero voltage drop upon transfer to battery backup.

Altronix AL400ULACM Access Power Controller Features

  • Filtered and electronically regulated outputs: Ensures stable supply voltage for connected devices, reducing the risk of damage.
  • Short circuit and thermal overload protection: Safeguards the system and connected devices by automatically shutting down in case of faults.
  • Built-in charger for sealed lead acid or gel type battery backup: Provides reliable emergency power during outages, ensuring continued operation.
  • AC input and DC output LED indicators: Allows for easy monitoring of the system status, enhancing user experience.
  • Low battery and battery presence supervision: Alerts users to potential power issues, preventing unexpected failures.

Altronix AL400ULACM Detailed Specifications

AC Input115VAC
Input Frequency60Hz
DC Output Voltage12VDC @ 4A / 24VDC @ 3A
Number of Outputs8 outputs, independently controlled
Output TypeFail-Safe and/or Fail-Secure
Charger TypeSealed lead acid or gel type
Protection FeaturesShort circuit and thermal overload
LED IndicatorsAC input and DC output
Emergency FeatureFire alarm disconnect
EnclosureBC400 Enclosure
SKU  AL400ULACM
Manufacturer  Altronix
Output TypeDC
VersionIndoor Wallmount
Input Voltage115VAC
Number of Outputs  8
Output Protection  Fuse
Fire Alarm InterfaceYes
Battery Charging  Yes
Power Options3 amp @ 24VDC, 4 amp @ 12VDC
Certifications  CSFM, MEA, UL
