EverFocus NVR8004X-4T 20 Channel Elite2 NVR, 4TB
SKU
NVR8004X-4T
Model No
NVR8004X-4T
$938.77
Product Highlights
- Elite NVR8004X-4T can support up to 20 channel
- Hard Drive Configurations in up to 16 TB
- 4 HDD Bays with removable hot swap trays
- Dual NIC for separation of streaming camera video form LAN/WAN monitoring network
- Built-in web server for single NVR live/playback viewing and configuration
Speak to an expert
The EverFocus Elite 2 NVR8004X-4T is a powerful and advanced standalone network video recorder tailored for small to medium-sized businesses and enterprises. With its Linux-based architecture, this next-generation NVR offers fast and intuitive PC-less setup, seamless network connectivity for surveillance, and high-definition megapixel recording and playback. Boasting support for up to 16TB of storage and featuring robust industry-standard H.264 compression, this device ensures you get maximum efficiency with your surveillance operations. Its multi-channel playback capabilities and enhanced event management functionalities provide businesses with comprehensive monitoring and security solutions across a variety of settings.
EverFocus NVR8004X-4T Camera Features
- Support for Up to 20 Channels: This enables you to manage multiple cameras simultaneously, providing extensive coverage and surveillance for your premises.
- Storage Capacity of Up to 16 TB: Experience peace of mind with ample storage for high-resolution video files, ensuring vital footage is retained for future reference.
- 4 HDD Bays with Removable Hot Swap Trays: This design allows for easy replacement of hard drives without needing to power down the system, ensuring minimal disruption to surveillance operations.
- Dual NIC Configuration: This feature allows for dedicated streaming of camera footage separate from the monitoring network, optimizing performance and security.
- Built-in Web Server: Enables convenient live and playback viewing along with configuration settings directly from a web browser, enhancing user accessibility and control.
- Configurable Raid Options: Supports RAID configurations (0,1,5,6,10), providing flexibility in data redundancy and performance balancing.
- Free Multi-site CMS Software: Manage and monitor multiple NVRs easily with the included content management system, offering live and playback views across 32 cameras simultaneously.
Detailed Specifications for EverFocus NVR8004X-4T
| Brand | EverFocus |
| Model | NVR8004X-4T |
| Channels Supported | Up to 20 |
| Max Storage Capacity | 16 TB |
| HDD Bays | 4 with Hot Swap |
| NIC Configuration | Dual |
| Web Server | Built-in for Live & Playback |
| RAID Support | 0,1,5,6,10 |
| Multi-site CMS Capability | Up to 32 Live/16 Playback Cameras |
SKU  | NVR8004X-4T |
|---|---|
| Manufacturer | EverFocus |
| IP Channels | 20 channels |
| Harddrive Size | 4TB |
| Protocols | Onvif Protocols |
| Features | Audio, Centralized E-map, H.264 Compression, Supports PTZ Control, Two-way Audio |
Compression  | H.264 |
| Operating temperature | 32°F~104°F |
| Dimensions | 5.51” x 7.16” x 8.62” |
| Voltage | DC 19VDC , 4.74A |
| Power Consumption | 90W max |
| Network | 2x Gigabit RJ45 Ethernet Port |
| USB | 2x USB 2.0 2x USB 3.0(on back panel) |
| Audio | Bi-directional transmission, 1 audio channel per video channel |
| Frame Rate/Camera | Max 30FPS per camera |
| Centralized E-map | Yes |
| Two Way Audio | Yes |
| Supports PTZ Control | Yes |
| H.264 Compression | Yes |
