Veilux VEX-Thermal-100 Explosion Proof Thermal Imaging Camera, 100mm

The VEX-Thermal-100 from Veilux is an explosion proof thermal imaging camera designed for high-performance applications in hazardous environments, offering exceptional image clarity and durability.

Veilux VEX-Thermal-100 Camera Features

• Uncooled VOx Microbolometer Sensor: Provides high sensitivity and outstanding image quality for precise thermal measurements.
• 17 m Pixel Pitch: Ensures high-resolution images for accurate analysis and detection of heat sources.
• 640x480 FPA/ Digital Video Display Format: Delivers sharp and detailed thermal imaging for enhanced visibility in various conditions.
• 7.5-13.5 m Spectral Band: Effective for a wide range of thermal applications, enabling detection of different heat signatures.
• Scene Range (High Gain): -25°C ~ +135°C; ideal for capturing thermal data in normal operating conditions.
• Scene Range (Low Gain): -40°C ~ +550°C; extends capability to monitor extremely high temperature scenarios.
• Up to 8x Digital Zoom: Allows detailed inspection of distant objects without losing image quality.
• 560TV Lines of Resolution: Ensures clear and crisp thermal images for reliable information during inspections.
• IP67 rated: Fully dust-tight and resistant to water immersion, providing reliable operation in harsh environments.
• 360° Continuous Pan Rotation / 10° per second (max.): Enhances flexibility and coverage, allowing for comprehensive thermal assessments.
• -90° ~ +90° Tilt Range: Facilitates easy viewing angles, essential for detailed inspections in varied positions.
• Stainless Steel construction: Ensures durability and corrosion resistance in explosive environments.

Veilux VEX-Thermal-100 Detailed Specifications
