GE Security Interlogix TVA-1101 TruVision Covert Camera, 1.3MPx, WDR, Digital D/N, Single Lens, PAL
- 1/3" CMOS image sensor
- 1280 X 960 resolution
- 0.01 lux (color)
- H.264 compression with triple-streaming capability
- ONVIF Profile S open standards design
The Interlogix TruVision 1.3MPx Covert IP Camera delivers highdefinition images for exceptional surveillance performance. Featuring 1.3MPx resolution and advanced signal processing capability, this camera represents an IP solution for retail, banking, airports, gaming and other applications where video camera concealment is desirable. In addition, the privacy mask feature can be used to conceal sensitive areas and safeguards confidential locations. Bandwidth usage is easily managed through H.264 compression with triple streaming capability. Video streams can be set for high and low bandwidth with images streamed for live viewing or sent to designated recording locations. For enhanced compatibility, this camera adheres to ONVIF Profile S open standards and supports a CGI command set for simple integration into any IP system. The 1.3MPx Covert IP Camera also simplifies remote, live monitoring and playback of edge-recorded video and audio. A built-in micro SD/SDHC/SDXC memory card slot supports the ability to provide redundancy if an unexpected network disruption were to occur.
Features
- 1/3" CMOS image sensor
- 1280 X 960 resolution
- 0.01 lux (color)
- H.264 compression with triple-streaming capability
- ONVIF Profile S open standards design
- Digital day/night
- Up to 120dB WDR
- Region of Interest (ROI) function
- Micro SD/SDHS/SDXC card slot - supports up to 64GB (card not included)
- Bi-directional audio
- Alarm inputs and outputs
- Embedded Video Intelligence: Cross line, Intrusion, De-focus and Face Detection capabilities
SKU  | TVA-1101 |
|---|---|
| Features | Auto Gain Control, Day/Night, Digital Noise Reduction, Motion Detection Tracking, On Screen Display Menu, ONVIF, Privacy Masking, Wide Dynamic Range |
| Manufacturer | Interlogix |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | Non Infrared |
| Resolution | 1.2 Megapixel |
| Lens Type | Not Included |
| Compression Method | H.264, MPEG-4, M-JPEG |
| Durability | Indoor |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | 3.07 × 4.13 × 1.26 in. (78 × 105 × 32mm) |
| Electronic Shutter | 1s - 1/100,000s |
| Image Device | 1.3MPx 1/3" Progressive Scan CMOS |
| Minimum Scene Illumination | 0.01 lux @ f1.2, AGC ON (Color) |
| Operating Temperature | -22°F~140°F (-30°C~60°C) |
| OSD Menu | Text overlay and picture overlay |
| Power Consumption | Max. 6.5W |
| Signal System | PAL |
| Digital Noise Reduction | 3D DNR |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Motion Detection Tracking | Yes |
| On Screen Display Menu | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
TVA-1101-Specsheet TVA-1101-Installation-Manual
