Bosch AL800LGK9E Logic Board, al800lgk9e

The AL800LGK9E Logic Board is a reliable and efficient replacement board designed specifically for the AL802-WAL NAC and AL1002WAL Power Extender enclosures. This logic board enhances system performance with its robust features, ensuring seamless operation and increased safety in power management applications.

Bosch AL800LGK9E Logic Board Features

• Class 2 rated power-limited outputs: Ensures compliance with safety standards, minimizing the risk of electric shock and enhancing system reliability.
• Two (2) Class A or two (2) Class B FACP inputs: Offers versatility in connection options to better suit various application needs and layouts.
• Two (2) NC dry contact trigger inputs: Allows integration with other systems or alarms for enhanced security and control capabilities.
• Two (2) Class A or four (4) Class B notification circuits: Supports expanded notification networks, with the option to parallel outputs for increased power on circuits, ensuring efficient alarm notifications.
• One (1) auxiliary power output at 1 A supply current with battery back up: Provides additional power reliability, ensuring critical components remain operational during outages.

Detailed Specifications for Bosch AL800LGK9E
