Ganz ZN8-F12F18-NIR 12 Megapixel Outdoor 360° Fisheye Dome Camera, 1.8mm Lens
SKU
ZN8-F12F18-NIR
Model No
ZN8-F12F18-NIR
$538.86
Product Highlights
- 12 Megapixel Resolution
- 1/1.7″ Progressive Scan CMOS
- 360° Panoramic
- 3D DNR, dWDR, ICR, HLC, BLC
- 6 IR LEDs (30' range)
Speak to an expert
The ZN8-F12F18-NIR from Ganz is a 12 megapixel outdoor 360° fisheye dome camera, 1.8 mm lens. Its unique dewarping function allows a non-distorted view of the 360-degree image. The dome features 6 IR LEDs suitable for up to 30' range. IP67 rated for all weather conditions.
Ganz ZN8-F12F18-NIR Camera Features
- 12 Megapixel Resolution: Delivers high-definition imagery, ensuring every detail is captured clearly.
- 1/1.7” Progressive Scan CMOS: Provides superior image quality, ideal for both day and night surveillance.
- 360° Panoramic: Offers extensive coverage without blind spots, making it perfect for large areas.
- 3D DNR, dWDR, ICR, HLC, BLC: Advanced imaging technologies that enhance video quality in varying light conditions.
- 6 IR LEDs (30’ range): Ensures visibility at night, making it effective for 24/7 monitoring.
- Dewarp on camera: Eliminates distortion in the panoramic view, providing a rectified image for better analysis.
- PoE / 12VDC / 24VAC: Flexible power options allow for diverse installation scenarios.
- IP67 for all weather conditions: Designed to withstand harsh environments, ensuring reliability in outdoor settings.
Detailed Specifications for Ganz ZN8-F12F18-NIR
| Camera Type | Outdoor 360° Fisheye Dome |
| Resolution | 12 Megapixels |
| Lens | 1.8mm |
| IR Range | 30 feet |
| IP Rating | IP67 |
| Power Options | PoE / 12VDC / 24VAC |
| Features | Dewarping, 3D DNR, dWDR, ICR, HLC, BLC |
| Sensor Type | 1/1.7” Progressive Scan CMOS |
SKU  | ZN8-F12F18-NIR |
|---|---|
| Features | Audio, Auto Gain Control, Back Light Compensation, Day/Night, Digital Noise Reduction, Motion Detection Tracking, On Screen Display Menu, ONVIF, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Ganz |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 61~100 Feet |
| Resolution | 12 Megapixel |
| Lens Type | Fixed |
| Lens Size | 1.8mm |
| Mount Type | Ceiling, Wall |
| Compression Method | M-JPEG, H.265 |
| Durability | Weather Resistant |
| Voltage | 12vDC, 24vAC, PoE |
| Dimensions (W x H) | 6.3”(Ø) x 1.8”(H) / 160mm(Ø) x 46.8mm(H) |
| Electronic Shutter | 1/5 - 1/20000 |
| Image Device | 1/1.7” Progressive Scan CMOS |
| IR LEDs | 6 |
| Minimum Scene Illumination | Color: 0.009 Lux@ (F1.2,AGC ON), B/W: 0 Lux@ (IR LED O N) |
| Operating Humidity | 0% - 90% RH |
| Operating Temperature | -13°F ~ 131°F |
| OSD Menu | English, Chinese, Polish, Italian, Portuguese, Spanish. Russian, French, Czech, Hungarian |
| Power Consumption | 5W (IR LED Off) / 8W IR LED (On) |
| Protocols | IPv4, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ICMP, IGMP, Unicast & Multicast |
| Weatherproof | IP67 |
| Digital Noise Reduction | 2D / 3D |
| Angle of View | 360° |
| IR Distance | 30m/98.42ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| On Screen Display Menu | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
