Bogen TPU35B Telephone Paging Amplifier, 35W

The TPU35B from Bogen is a powerful telephone paging amplifier that offers 35 watts of high-quality sound, making it perfect for any office or retail environment. It comes with multiple input options, automatic level control, and a range of customizable sound settings, ensuring clear communication and an enhanced audio experience for paging and background music.

Features

• 35 Watt Model: Provides ample power for effective paging and background music amplification in various settings.
• Multiple Inputs: Supports 600-ohm balanced telephone lines, Lo-Z balanced microphones, and background music sources for versatile connectivity.
• Music Input: Includes RCA jack or screw terminals for easy music source integration.
• Automatic Level Control (ALC): Helps maintain consistent volume levels regardless of speaker's voice, ensuring clear paging.
• Page from Any Source: Capability to page from both telephone and microphone, allowing for flexible communication options.
• Signal-Activated Paging Channel: Automatically mutes background music when a page is made, ensuring clarity of messages.
• Adjustable Music Muting Level: Lets users customize the level of music muting during a page for balanced audio.
• Gradual Music Return: Ensures a smooth transition back to normal music levels after paging, enhancing listener experience.
• Audio Enhancement Circuit: Improves intelligibility and loudness without increasing power, reducing listener fatigue.
• Separate Volume Controls: Allows independent adjustments for page volume, music volume, night ringer, music mute, and audio enhancement.
• Bass and Treble Controls: Users can tailor the audio output to their preferences for optimal sound quality.
• Built-In Night Ringer: Activated by contact closure or 90V ring signal to enhance paging functionality at night.
• Output Options: Balanced or unbalanced 16-ohm, 25V, 25V CT, and 70V outputs accommodate various speaker configurations.
• VOX Sensitivity Control: Prevents accidental transmissions of background noise, maintaining clear communication.
• Overload Protection: Thermal and electronic overload protection ensures the amplifier operates safely under all conditions.
• Bridging Capability: Jacks provided for connecting additional TPU amplifiers for expanded coverage.
• Peak Level Indicator: Visual indicator that lights up when the amplifier is close to clipping, helping to prevent distortion.
• Power Source: Operates on a standard 120V AC, 60 Hz power source for easy installation.
• UL Listed: Complies with UL Standard 60065 for safety in the U.S. and Canada.

Bogen TPU35B Detailed Specifications
