Louroe Electronics LE-224 4 Zone Distribution Amplifier

The LE-224 is an Audio Distribution Amplifier with one audio input and four audio outputs. It receives line level audio signals from a Louroe base station or Louroe microphone and distributes it to up to four devices such as DVR’s, VCR’s, CCTV monitors with amplifiers or other audio devices that accept line level input. Each output of the DA4 has a gain adjust potentiometer for correcting audio level. Maximum gain is 15dB when potentiometer is fully engaged. Included with the LE-224 are five RCA connector cables and a 12Vdc power supply.

Features

• One audio input and four audio outputs (RCA)
• Power jack for applying 12Vdc power
• 120V/12Vdc power supply included
• Gain adjust for each audio output
• LED power indicator

Downloads

  LE-224-Specsheet

  LE-224-Installation-Manual
